Mirror polished tungsten carbide tiles

Mirror polished tungsten carbide tiles

【Item】Mirror polished tungsten carbide tiles

【Grade】JZ2T (k10~k20)

【Specification】According to customer requirement

【Brand】HAO Carbide

【Country of Origin】ZhuZhou, China

【Usage】wood cutters / hard wood cutters, plastic and tobacco cutting

E-mail This Page Submit Your Inquiry
Product info


1. Hardness can reach to HRA 94, TRS ≥4000 N/mm²

2. The sizes of the strips can be customized as your requirements.

3. Blank strips and polished strips can be chosen.

4. The minimum size is φd 0.25mm and the tolerance can reach to ±0.01mm.

5. Common diameter from 1mm---30mm

6. length tolerance: +0.3--1.8mm

Product features:

1.Our cemented carbide rods use dry isostatic pressing machine and low press sintering technology,
which showed uniform distribution of cobalt magnetic, high hardness and bending strength.

2. Inner structure are more compact and well distributed in metallographic test.

3. It can reach a mirror effect surface after accurate grinding.




Tungsten Carbide Plates Tags
Carbide Sharpener Ferro Rod, Tungsten Carbide Rods, Tungsten Rods For Welding,
Product Dispaly
Specifications

Specificataon List of Carbide tiles


Properties and applications of tunqsten carbide strips

GRADE JZ6 JZ6A JZ8 JZ2T JZ10.2
ISO CODE K10 K10 K20 K10~K20 K20~K30
CO (%) 6 6 8 15 10
WC (%) 94 94 92 85 90
DENSITY (G/cm3) 14.9 14.9 14.7 14.5 14.45
T.R.S (Mpa) 2150 1850 2400 2350 2400
Hardness (HRA) 90 92 89.5 92 91.5


GRADE Properties and Applications
JZ6 Good wear resistance, used for hard wood, used for processing original wood, aluminum setion bar, brass rod and cast iron.
JZ6A Has wear resistance higher than YG6, used for processing hard wood, original wood, aluminum setion bar, brass rod and cast iron.
JZ8 Used for punch dies, stamping dies and wear resistance parts.
JZ2T Fine carbide, high wear resistance, high bending strength, high resistance to bonding, high thermal strength. Machining of refractory alloys, stainless steel and high manganese steel, etc.
JZ10.2 It suitable for making low and medium speed electronic class level dies, also applying in punching copper or aluminum strip.
